6

- 6 -

4p4c plug

Pin Assignment

Sub-D 15

(male)

Sub-D 9

(female)

Plug

4P4C

11

23

3

41

54

62

76

84

95

10 2

11 8

12 7

13 9

14

15 3

Sub-D 9 pin

‘Y’ cable

- Direct connection with standard 9-

pin RS-232 port (DTE)

- Direct connection with common

handset of telephone for voice call

- Shielded cable

- Cable length 1.1m (w/ connector)

DIN rail mount

- Quick attachment / detachment to

standard DIN rail

- Tin plated Steel
