Printer Initialization

Printer initialization is used to clear DRAM and restore printer settings to defaults.

Printer initialization is activated by the following procedures.

1. Turn off the power switch.

2. Hold on the button then turn on the power switch.

3. Release the button when LED turns green after 5 amber blinks. (Any green will do

during the 5 blinks).

 The LED color will be changed as following:

Amber  red (5 blinks)  amber (5 blinks)  green (5 blinks)  green/amber (5

blinks)  red/amber (5 blinks)  solid green

Printer configuration will be restored to defaults as below after initialization.

Parameter

Default setting

Speed

127 mm/sec (5 ips) (203DPI)

76.2 mm/sec (3 ips) (300DPI)

Density

Label Width

2” (50.8 mm)

Label Height

2” (50.8 mm)

Sensor Type

Gap sensor

Gap Setting

0.12” (3.0 mm)

Print Direction

Reference Point

0,0 (upper left corner)

Offset

Tear Mode

Peel off Mode

Off

Cutter Mode

Off

Serial Port Settings

9600 bps, none parity, 8 data bits, 1 stop bit

Code Page

850

Country Code

001

Clear Flash Memory

IP Address

DHCP
