Wavecom Instruments Thermal Transfer Bar Code Printer User Manual

Interior View

1. Ribbon access cover 8. Media guide

2. Ribbon rewind hub 9. Top cover support

3. Ribbon rewind gear 10. Black mark sensor

4. Print head 11. Platen roller

5. Ribbon supply hub 12. Gap sensor (transmitter)

6. Gap sensor (receiver) 13. Media guide adjuster knob

7. Media holders 14. Top cover
